Ranger Point Precision Australia Henry Ranger M-LOK Handguard (Black)
Sale

Ranger Point Precision

Henry Ranger M-LOK Handguard (Black)

(No reviews yet) Write a Review
$300.00
SKU:
8007
Availability:
All orders ship within 7 days
Adding to cart… The item has been added

Description

MADE IN AMERICA:
MADE IN TEXAS
FEATURES:
3 Flush Cup holes for sling swivels, 1 Trad sling stud hole, 24 M-LOK slots, 18 finger grooves per side
FITS:
Henry models (all calibers): Side Gates, X Series, Color Case Hardened 30-30, Big Boy Steels, All Weather, .410 Axe rifles
DOES NOT FIT:
Color Case Hardened 45-70 (H010GCC); Golden Boys (H006 or personal engraved),Henry Classic Brass Receivers, Long Rangers, Single Shots, 22 Rimfires, Barrel band models
NEED HELP WITH INSTALLATION?:
Contact Armed Concepts, TX Arsenal or JOJO's Gun Works.
LOADING PORT CUTOUT:
Does not block your ability to load via the mag tube underside load port or front of the mag tube.
MATERIAL:
6061-T6 aluminum (Type III Black anodized)
WEIGHT:
7.5 oz (similar to the factory forearm)
HANDGUARD LENGTH:
13.25" Length (exposed opening mag tube loading port)
INSTALLATION (comes with hardware):
Watch the install video from customers. Taking Henry's apart can be tricky. We're not liable for any damage to your rifle. If needed, Louthan Gunworks has agreed to do $65 installs + return shipping. Contact them directly to make arrangements.
MLOK 6-8 CARTRIDGE QUIVERS:
Available on our website for 45-70 govt, 30-30 Win, 444, 44 Mag, 45 Colt, 357 Mag.



In the Package: one 13.25" long mlok handguard + hardware

Mlok Handguard Features:

Take a look at the full list of tweaks and features

  • Machined from one piece of solid billet aluminum for increased rigidity and reduced weight.
  • Full length 13.25" total length x 1.5" width x " 1.6" height x 7.5 oz length with exposed mag tube loading port.
  • Hardware is provided increasing durability and load bearing capacity while ensuring easy installation
  • Four set screws afford rock solid bedding and eliminate lateral shift.
  • Even easier DIY installation.
  • Extra M-LOKs slots on sides–now 24 slots total
  • Four Flush Cup holes for push button sling swivels
  • Smoother, cleaner lines on each side with dedicated parts for different rifle models.
  • Flat bottom provides increased stability when shooting from a rest, while the slender width, deep finger grooves and rounded lower corners offer comfortable, confident ergos
  • Increased grip on bottom, with leaf voids cut into corner radii.
  • Improved compatibility with shortened barrels and suppressors.
  • M lok Rail all parts chamfered, deburred, and tumbled to provide a smooth comfortable finish with no cheese grater effect
  • Always made in the USA.

Warranty Information

Ranger Point Precision – Limited Lifetime Warranty (Australia) As the official Australian partner of Ranger Point Precision, we proudly honour RPP’s Limited Lifetime Warranty for all products purchased through our store. This warranty covers RPP parts for the lifetime of the original purchaser, excluding cases of: Intentional abuse or neglect Unauthorised modifications or alterations Damage caused by incorrect installation or use Normal cosmetic wear (e.g. finish rub or discolouration) Exposure-related damage (e.g. rust from water, flame, or environmental factors) Purchases made second-hand or via unauthorised resellers (e.g. eBay, private sales) If a defect is found and approved, we will replace the part with a new one, or provide store credit if a replacement is not available. What's Covered: All manufacturing defects Failures due to faulty materials or workmanship What's Not Covered: Stripped or broken fasteners from over-torquing or incorrect tool use Finish wear from normal use Environmental damage (oxidation, rust, etc.) Parts not purchased through our store or authorised resellers
